- Product Name:860-960Mhz 10M Long Range Passive RFID On metal Sticker
- Product Model:NR-9525
Cantact Us:
- Product Overview
860-960Mhz 10M Long Range Passive RFID On metal tal Sticker Tag
R-K9525 is a general-purpose UHF anti-metal tag made of PCB material. In the market, its reading range performance can reach or exceed other tags that are about 10CM longer. Its moderate size is one of the most widely used tags.
Typical Features
The surface of the product is smooth and flat, without the protruding due to chip packaging；
Any label with printed or printed content can be pasted on the surface of the product；
The tag surface can also be exquisite silk screen；
Product reading distance；
Product installation is flexible and convenient；
Application
Warehouse shelf management；
Warehouse locomotive equipment management；
IT facility chassis management；
Management of large and medium metal containers；
Power box, power facility management；
Indoor office equipment and facility management with metal casing；
Building wall or column management (built-in)；
Personnel inspection management；
Management of public facilities such as street lights and traffic light poles；
Large and medium-sized fluid valve or pipeline management；
Functional Specifications
Physical Specification
Reliability Specification
*The above test is the test result under the laboratory standard conditions. In the actual use environment, due to
the many and complicated influencing factors, the final condition of the product may be different from the use environment.
Performance Characteristics
R-K9525 is a general-purpose UHF anti-metal tag made of PCB material. In the market, its reading range performance can reach or exceed other tags that are about 10CM longer. Its moderate size is one of the most widely used tags.
Typical Features
The surface of the product is smooth and flat, without the protruding due to chip packaging；
Any label with printed or printed content can be pasted on the surface of the product；
The tag surface can also be exquisite silk screen；
Product reading distance；
Product installation is flexible and convenient；
Application
Warehouse shelf management；
Warehouse locomotive equipment management；
IT facility chassis management；
Management of large and medium metal containers；
Power box, power facility management；
Indoor office equipment and facility management with metal casing；
Building wall or column management (built-in)；
Personnel inspection management；
Management of public facilities such as street lights and traffic light poles；
Large and medium-sized fluid valve or pipeline management；
Functional Specifications
| Protocol | EPC Class1 Gen2; ISO18000-6C |
| Frequency | 902-928MHz (Other frequencies available for the same size) |
| Chip | Impinj M4QT(Other chips available in the same size) |
| Chip memory | EPC 128bits, USER 512bits |
| Read and write performance | Readable and writable (customers can write content repeatedly into the chip) |
| Data saving | 50 years |
| Warranty | 1 year |
Physical Specification
| Main material | FR4 |
| Color | Black |
| Size | 95 *25 *3.4mm |
| Working temperature | -25℃~ +95℃ |
| Storage temperature | -40℃~ +120℃ |
| Storage Humidity | 5%～95% |
| Installation method | 3M300LSE adhesive, or screws, rivets, super glue |
| Weight | 12g/piece |
| Package | 2100 per box, 0.0244 cubic meters per box |
Reliability Specification
| Drop test | Passed 200 times drop test at 1 meter height |
| Alcohol test | 95% alcohol test passed |
| Gasoline test | No. 92 gasoline wipe passed |
| High and low temperature alternating | -40℃～+95℃100 high and low temperature alternating cycles, a total of 30 consecutive days passed the test |
| Rapid cooling test | After heating at 185 degrees for 1.5 hours, put it in 10 degrees water quickly and accurately, take it out and pass the function test at room temperature |
| RoHS | Pass |
| IP Grade | IP68 |
*The above test is the test result under the laboratory standard conditions. In the actual use environment, due to
the many and complicated influencing factors, the final condition of the product may be different from the use environment.
Performance Characteristics
| Fixed reader (on metal) | More than 15 meters (12dbi long-distance fixed reader, if other readers, the reading distance may be different) |
| Handheld reader (on metal) | More than 8 meters (reading distance under 5dBi clamshell circularly polarized antenna in open outdoor occasions, if other handhelds are used, the reading distance may be different) |
| Tag polarization | Linear polarization |
| Tag starting power | Less than -12dBm@920MHz |
| Tag radiation power | More than - 20dBm@920MHz |
| Tag gain | More than -6dBi |
| (The test is based on -75dB device sensitivity and 6dBi linear polarized antenna. Please contact sales staff for specific test information) | |
